R Axial DIN0614 L14.3mm D5.7mm P15.24mm Horizontal

Skills Contribute

passiveresistorthrough-hole

Loading R Axial DIN0614 L14.3mm D5.7mm P15.24mm Horizontal 3D viewer

Summary

Through-hole resistor footprint model, R Axial DIN0614 L14.3mm D5.7mm P15.24mm Horizontal.

Part

Category: electronics
Family: resistor-tht
Step Source: https://gitlab.com/kicad/libraries/kicad-packages3D/-/raw/0bc64e922178140eb6890377646efd45e15011bd/Resistor_THT.3dshapes/R_Axial_DIN0614_L14.3mm_D5.7mm_P15.24mm_Horizontal.step
Model: R_Axial_DIN0614_L14.3mm_D5.7mm_P15.24mm_Horizontal
Mounting Style: through-hole
Pitch mm: 15.24
