r_axial_din0411_l9_9mm_d3_6mm_p12_70mm_horizontal.step

R Axial DIN0411 L9.9mm D3.6mm P12.70mm Horizontal

Skills Contribute

passiveresistorthrough-hole

Loading R Axial DIN0411 L9.9mm D3.6mm P12.70mm Horizontal 3D viewer

Summary

Through-hole resistor footprint model, R Axial DIN0411 L9.9mm D3.6mm P12.70mm Horizontal.

Part

Category: electronics
Family: resistor-tht
Step Source: https://gitlab.com/kicad/libraries/kicad-packages3D/-/raw/0bc64e922178140eb6890377646efd45e15011bd/Resistor_THT.3dshapes/R_Axial_DIN0411_L9.9mm_D3.6mm_P12.70mm_Horizontal.step
Model: R_Axial_DIN0411_L9.9mm_D3.6mm_P12.70mm_Horizontal
Mounting Style: through-hole
Pitch mm: 12.7
