pinheader_1x26_p1_27mm_vertical_smd_pin1left.step

Pin Header 1x26 P1.27mm Vertical SMD Pin1Left

Skills Contribute

connectorboard-to-boardpin-header

Loading Pin Header 1x26 P1.27mm Vertical SMD Pin1Left 3D viewer

Summary

Pin header, Pin Header 1x26 P1.27mm Vertical SMD Pin1Left.

Part

Category: electronics
Family: 1-27-mm-pitch-pin-header
Model: PinHeader_1x26_P1.27mm_Vertical_SMD_Pin1Left
Pitch mm: 1.27
