phoenixcontact_spt_2_5_6_h_5_0_1x06_p5_0mm_horizontal.step

Phoenix Contact SPT 2.5 6-H-5.0 1x06 P5.0mm Horizontal

Skills Contribute

connectorterminal-blockwire-to-board

Loading Phoenix Contact SPT 2.5 6-H-5.0 1x06 P5.0mm Horizontal 3D viewer

Summary

Connector Phoenix SPT connector footprint model, Phoenix Contact SPT 2.5 6-H-5.0 1x06 P5.0mm Horizontal.

Part

Category: electronics
Family: connector-phoenix-spt
Step Source: https://gitlab.com/kicad/libraries/kicad-packages3D/-/raw/0bc64e922178140eb6890377646efd45e15011bd/Connector_Phoenix_SPT.3dshapes/PhoenixContact_SPT_2.5_6-H-5.0_1x06_P5.0mm_Horizontal.step
Model: PhoenixContact_SPT_2.5_6-H-5.0_1x06_P5.0mm_Horizontal
Manufacturer: Phoenix Contact
Pitch mm: 5
