phoenixcontact_spt_1_5_9_h_3_5_1x09_p3_5mm_horizontal.step

Phoenix Contact SPT 1.5 9-H-3.5 1x09 P3.5mm Horizontal

Skills Contribute

connectorterminal-blockwire-to-board

Loading Phoenix Contact SPT 1.5 9-H-3.5 1x09 P3.5mm Horizontal 3D viewer

Summary

Connector Phoenix SPT connector footprint model, Phoenix Contact SPT 1.5 9-H-3.5 1x09 P3.5mm Horizontal.

Part

Category: electronics
Family: connector-phoenix-spt
Step Source: https://gitlab.com/kicad/libraries/kicad-packages3D/-/raw/0bc64e922178140eb6890377646efd45e15011bd/Connector_Phoenix_SPT.3dshapes/PhoenixContact_SPT_1.5_9-H-3.5_1x09_P3.5mm_Horizontal.step
Model: PhoenixContact_SPT_1.5_9-H-3.5_1x09_P3.5mm_Horizontal
Manufacturer: Phoenix Contact
Pitch mm: 3.5
