l_axial_l14_5mm_d5_8mm_p20_32mm_horizontal_fastron_hbcc.step

L Axial L14.5mm D5.8mm P20.32mm Horizontal Fastron HBCC

Skills Contribute

passiveinductorferritethrough-hole

Loading L Axial L14.5mm D5.8mm P20.32mm Horizontal Fastron HBCC 3D viewer

Summary

Through-hole inductor footprint model, L Axial L14.5mm D5.8mm P20.32mm Horizontal Fastron HBCC.

Part

Category: electronics
Family: inductor-tht
Step Source: https://gitlab.com/kicad/libraries/kicad-packages3D/-/raw/0bc64e922178140eb6890377646efd45e15011bd/Inductor_THT.3dshapes/L_Axial_L14.5mm_D5.8mm_P20.32mm_Horizontal_Fastron_HBCC.step
Model: L_Axial_L14.5mm_D5.8mm_P20.32mm_Horizontal_Fastron_HBCC
Mounting Style: through-hole
Pitch mm: 20.32
