asme_socket_set_screw_cup_point_n2_56_l0p125in_simple.step

Imperial set screws / grub screws, #2-56, cup point, L=0.125 in, simplified thread

Skills Contribute

screw

Loading Imperial set screws / grub screws, #2-56, cup point, L=0.125 in, simplified thread 3D viewer

Summary

Imperial set screw/grub screw, #2-56, cup point, L=0.125 in.

Part

Category: fastener
Family: asme-set-screw-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: set_screw
Length In: 0.125
Length mm: 3.175
Major Diameter In: 0.086
Thread: #2-56
Threads Per Inch: 56
Nominal Size: #2-56 x 3.175 mm
