asme_socket_set_screw_cup_point_5_16_18_l0p25in_simple.step

Imperial set screws / grub screws, 5/16-18, cup point, L=0.25 in, simplified thread

Skills Contribute

screw

Loading Imperial set screws / grub screws, 5/16-18, cup point, L=0.25 in, simplified thread 3D viewer

Summary

Imperial set screw/grub screw, 5/16-18, cup point, L=0.25 in.

Part

Category: fastener
Family: asme-set-screw-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: set_screw
Length In: 0.25
Length mm: 6.35
Major Diameter In: 0.3125
Thread: 5/16-18
Threads Per Inch: 18
Nominal Size: 5/16-18 x 6.35 mm
