asme_flat_head_socket_screw_n4_40_l0p375in_simple.step

Imperial flat/countersunk socket screws, #4-40, L=0.375 in, simplified thread

Skills Contribute

screwcountersunk

Loading Imperial flat/countersunk socket screws, #4-40, L=0.375 in, simplified thread 3D viewer

Summary

Imperial flat/countersunk socket screw, #4-40, L=0.375 in.

Part

Category: fastener
Family: asme-flat-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: flat_head
Length In: 0.375
Length mm: 9.524999999999999
Major Diameter In: 0.112
Thread: #4-40
Threads Per Inch: 40
Nominal Size: #4-40 x 9.525 mm
