asme_flat_head_socket_screw_n2_56_l0p1875in_simple.step

Imperial flat/countersunk socket screws, #2-56, L=0.1875 in, simplified thread

Skills Contribute

screwcountersunk

Loading Imperial flat/countersunk socket screws, #2-56, L=0.1875 in, simplified thread 3D viewer

Summary

Imperial flat/countersunk socket screw, #2-56, L=0.1875 in.

Part

Category: fastener
Family: asme-flat-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: flat_head
Length In: 0.1875
Length mm: 4.762499999999999
Major Diameter In: 0.086
Thread: #2-56
Threads Per Inch: 56
Nominal Size: #2-56 x 4.7625 mm
