asme_flat_head_socket_screw_1_2_20_l0p75in_simple.step

Imperial flat/countersunk socket screws, 1/2-20, L=0.75 in, simplified thread

Skills Contribute

screwcountersunk

Loading Imperial flat/countersunk socket screws, 1/2-20, L=0.75 in, simplified thread 3D viewer

Summary

Imperial flat/countersunk socket screw, 1/2-20, L=0.75 in.

Part

Category: fastener
Family: asme-flat-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: flat_head
Length In: 0.75
Length mm: 19.049999999999997
Thread: 1/2-20
Nominal Size: 1/2-20 x 19.05 mm
