asme_button_head_socket_screw_n10_32_l0p5in_simple.step

Imperial button-head socket screws, #10-32, L=0.5 in, simplified thread

Skills Contribute

screwsocket-headbutton-head

Loading Imperial button-head socket screws, #10-32, L=0.5 in, simplified thread 3D viewer

Summary

Imperial button-head socket screw, #10-32, L=0.5 in.

Part

Category: fastener
Family: asme-button-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: button_head
Length In: 0.5
Length mm: 12.7
Major Diameter In: 0.19
Thread: #10-32
Threads Per Inch: 32
Nominal Size: #10-32 x 12.7 mm
