asme_button_head_socket_screw_n0_80_l0p25in_simple.step

Imperial button-head socket screws, #0-80, L=0.25 in, simplified thread

Skills Contribute

screwsocket-headbutton-head

Loading Imperial button-head socket screws, #0-80, L=0.25 in, simplified thread 3D viewer

Summary

Imperial button-head socket screw, #0-80, L=0.25 in.

Part

Category: fastener
Family: asme-button-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: button_head
Length In: 0.25
Length mm: 6.35
Major Diameter In: 0.06
Thread: #0-80
Threads Per Inch: 80
Nominal Size: #0-80 x 6.35 mm
