asme_button_head_socket_screw_1_4_20_l0p75in_simple.step

Imperial button-head socket screws, 1/4-20, L=0.75 in, simplified thread

Skills Contribute

screwsocket-headbutton-head

Loading Imperial button-head socket screws, 1/4-20, L=0.75 in, simplified thread 3D viewer

Summary

Imperial button-head socket screw, 1/4-20, L=0.75 in.

Part

Category: fastener
Family: asme-button-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: button_head
Length In: 0.75
Length mm: 19.049999999999997
Major Diameter In: 0.25
Thread: 1/4-20
Threads Per Inch: 20
Nominal Size: 1/4-20 x 19.05 mm
