asme_button_head_socket_screw_1_2_13_l2p5in_simple.step

Imperial button-head socket screws, 1/2-13, L=2.5 in, simplified thread

Skills Contribute

screwsocket-headbutton-head

Loading Imperial button-head socket screws, 1/2-13, L=2.5 in, simplified thread 3D viewer

Summary

Imperial button-head socket screw, 1/2-13, L=2.5 in.

Part

Category: fastener
Family: asme-button-head-screw
Standard: ASME B18 generic
Standard Body: ASME
Standard Number: B18
Geometry Representation: analytic simplified
Head Style: button_head
Length In: 2.5
Length mm: 63.5
Major Diameter In: 0.5
Thread: 1/2-13
Threads Per Inch: 13
Nominal Size: 1/2-13 x 63.5 mm
