analog_msop_12_16_1ep_3x4_039mm_p0_5mm_ep1_651x2_845mm.step

Analog MSOP-12-16-1 EP 3x4.039mm P0.5mm EP1.651x2.845mm

Skills Contribute

semiconductorpackagesmd

Loading Analog MSOP-12-16-1 EP 3x4.039mm P0.5mm EP1.651x2.845mm 3D viewer

Summary

Package SO semiconductor package model, Analog MSOP-12-16-1 EP 3x4.039mm P0.5mm EP1.651x2.845mm.

Part

Category: electronics
Family: package-so
Step Source: https://gitlab.com/kicad/libraries/kicad-packages3D/-/raw/0bc64e922178140eb6890377646efd45e15011bd/Package_SO.3dshapes/Analog_MSOP-12-16-1EP_3x4.039mm_P0.5mm_EP1.651x2.845mm.step
Model: Analog_MSOP-12-16-1EP_3x4.039mm_P0.5mm_EP1.651x2.845mm
Pitch mm: 0.5
