adafruit_5360_mag_connector_3_pin_right_angle_pads.step

5360 Mag Connector (3-pin, Right Angle, Pads)

Skills Contribute

connector-cableconnector

Loading 5360 Mag Connector (3-pin, Right Angle, Pads) 3D viewer

Summary

Adafruit 5360 Mag Connector (3-pin, Right Angle, Pads).

Part

Category: electronics
Family: adafruit
Product Page: https://www.adafruit.com/product/5360
Step Source: https://raw.githubusercontent.com/adafruit/Adafruit_CAD_Parts/5ead410a8034146307aa99f2ab916bbd2a87114f/5360%20Mag%20Connector%20(3-pin%2C%20Right%20Angle)/5360%20Mag%20Connector%20(3-pin%2C%20Right%20Angle%2C%20Pads).step
Manufacturer: Adafruit
Model: 5360 Mag Connector (3-pin, Right Angle, Pads)
Form Factor: connector-cable
Sku: 5360
