adafruit_5359_mag_connector_5_pin_right_angle_pads.step

5359 Mag Connector (5-pin, Right Angle, Pads)

Skills Contribute

connectorwire-to-board

Loading 5359 Mag Connector (5-pin, Right Angle, Pads) 3D viewer

Summary

Adafruit 5359 Mag Connector (5-pin, Right Angle, Pads).

Part

Category: electronics
Family: adafruit
Product Page: https://www.adafruit.com/product/5359
Step Source: https://raw.githubusercontent.com/adafruit/Adafruit_CAD_Parts/5ead410a8034146307aa99f2ab916bbd2a87114f/5359%20Mag%20Connector%20%285-pin%2C%20Right%20Angle%29/5359%20Mag%20Connector%20%285-pin%2C%20Right%20Angle%2C%20Pads%29.step
Manufacturer: Adafruit
Model: 5359 Mag Connector (5-pin, Right Angle, Pads)
Form Factor: connector
Sku: 5359
